JideTech POE 4K 4CH IP 8CH NVR Security Camera System (NK2-4H-8MP)

$208.00
$208.00
Versand wird an der Kasse berechnet.

JideTech POE 4K 4CH IP 8CH NVR Security Camera System (NK2-4H-8MP)



Key Features:

  • 8 million pixels, enjoy ultra-high-definition picture quality
  • POE over power supply: the network cable is directly connected, just one wire meets the requirement of network + power supply, and the installation is convenient
  • H.265+ high compression ratio, reducing storage space and transmission bandwidth
  • Automatically add IPC, support plug and play
  • Support ONVIF protocol; can connect to third-party NVR and platform, also can connect to third-party IPC
  • Infrared white light dual-light design, supports three adjustable night vision modes to achieve full color at night
  • Active defense, when someone breaks into the warning area, the equipment will sound and light alarm
  •  Intelligent humanoid detection, filtering false positives, and accurately protecting your safety
  • Built-in high-sensitivity MIC and speaker, support two-way voice intercom
  • Support multi-channel remote monitoring of mobile phones and PC clients, and view the live scene anytime, anywhere

Specifications:

PoE NVR
Processor Industrial embedded microcontroller
Operating system Embedded LINUX operating system
Picture decoding 720P，960P，1080P ，3MP，4MP,5MP，8MP vedio encoding
Video interface 8*720P/960P/1080P/3MP/4MP/5MP/8MP
Video output 1080P@60fps，4K@30fps (1H VGA output, 1H HDMI output）
Video code Timing video、motion detection video
Video storage SATA hard disk*1, Maximum 6TB
Video playback 1*8MP playback；1*5MP playback；2*3MP playback； 8*1080P playback
Backup mode USB backup and Network backup
Network protocol TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,P2P
Mobile Phone app EseeCloud（Android, IOS）, Tuya is optional
Network interface 1*RJ45 10M/100Mbps adaptive Ethernet port
POE 4/8* PoE IEEE802.3af/RJ45 10M/100Mbps adaptive Ethernet port
USB 2*USB 2.0
Audio output 1*3.5mm audio interface (support HDMI audio output)
Audio intput
Power DC 48V /2A
Power Consumption 4H≈30W  8H≈58W
Working temperature -10℃~＋55℃
Working environment Indoor


IP Camera
Sensor 1/2.5” CMOS Sensor，Color: 0.1 Lux， Black/White: 0.01 Lux
Vedio coding H.264/H.265
Maximum resolution Main stream：3840x2160@15fps；sub-stream：720x576@15fps
Len 4mm
Function Support motion detection、JPEG screenshot
Night vision fill light IR light（20M)
Day and night IR-CUT IR Filter
Audio Optional, support voice intercom/built-in microphone
POE PoE IEEE802.3af
Interface 1*RJ45 10/100M adaptive Ethernet port
Protocol Support RTSP，DHCP，ONVIF，N1 private protocol
Power DC 12V /1A  / PoE
Dimension of box 320*180*320MM
Qty/CTN 4 Set/ CTN,
Dimension of Carton  660*380*330MM
Installation Universal
Working environment Indoor/outdoor
Protection grade IP66
